2009 BMW K1300R - Specifications
Engine
Power Unit
Configuration Water-cooled four-stroke straight-four,
two camshafts, four valves per cylinder
Bore x stroke 80 mm x 64.3 mm (3.15 x 2.53")
Capacity 1,293 cc
Max output 127 KW (173 hp) at 9,250 rpm
Max torque 140 Nm/103 lb-ft at 8,250 rpm
Compression ratio 13.0 : 1
Fuel supply/engine management
Electronic fuel injection, Digital Motor Electronics
with integrated knock control (BMS-K)
Valve/gas control DOHC (double overhead camshaft)
Diameter inlet 32
Diameter outlet 27,5
Throttle valve diameter 46
Exhaust management Fully controlled three-way catalyst,
EU3 emission standard
Performance/fuel consumption
Top speed 200 km/h (124 mph) +
Fuel consumption at a steady 90 km/h (56 mph)
5.0 ltr/100 km
Fuel consumption at a steady 120 km/h (75 mph)
5.8 ltr/100 km
Fuel grade Premium Plus, unleaded, 98 RON; automatic knock
control also enabling the engine to run on premium fuel down to 95 RON
Electrical System
Alternator 580 W three-phase alternator
Battery 12 V/14 Ah, maintenance-free
Power Transmission
Clutch Multiple-plate clutch in oil bath, hydraulically operated
Gearbox Dog-shift six-speed gearbox
Primary Transmission 1,559
Transmission, gear stages
I 2,398
II 1,871
III 1,525
IV 1,296
V 1,143
VI 1,015
Secondary drive Drive shaft
Suspension/Brakes
Frame Bridge frame, aluminium, load-bearing engine
Front wheel guidance/spring elements
BMW Motorrad Duolever; central spring strut
Rear wheel guidance/spring elements
Cast aluminium single swing arm with BMW Motorrad
Paralever; central spring strut with lever system,
spring pre-tension with infi nite hydraulic adjustment
by hand wheel, adjustable inbound damping
Spring travel, front/rear 115 mm/135 mm (4.52/5.31")
Wheelbase 1,585 mm (62.4")
Castor 104.4 mm (4.11")
Suspension/Brakes
Steering head angle 60.4�‹
Wheels Cast aluminium wheels
Rim, front 3.50 x 17"
Rim, rear 5.50 x 17"
Tyre, front 120/70 ZR 17
Tyre, rear 180/55 ZR 17
Brake, front Double-disc brake, fl oating brake discs, diameter
320 mm (12.6"), four-piston fi xed calliper
Brake, rear Single-disc brake, diameter 265 mm (10.4"),
double-piston swing calliper
ABS Optional: BMW Motorrad Integral ABS (semi-integral)
Dimensions/Weight
Seat height 820 mm (32.3") (low seat 790 mm/31.1")
Step arch length 1,810 mm (71.3") (low seat 1,750 mm/68.9")
Weight, unladen, in road trim and with full tank
243 kg (536 lb)
Dry weight 217 kg (478 lb)
Max permissible 460 kg (1,014 lb)
Max load (with motorcycle
in standard trim)
217 kg (478 lb)
Useful tank capacity 19 ltr
Thereof reserve approx 4.0 ltr
Length 2,228 mm (87.7")
Height (without mirrors) 1,095 mm (43.1")
Width (on mirrors) 856 mm (33.7")
